60/5000 Yī nián sìjì dōu kěyǐ shǐyòng de fēngshàn, bùjǐn jiàngwēn, dōngjì fǎn zhuǎn gèng kěyǐ diào wēn chuàngxīn kōngqì liútōng lǐniàn——chāodà zhíjìng, jìngyīn dīsù; dà fēngliàng, dīnéng hào, dī chéngběn. All year round can use the fan, not only cool, the winter reversal can thermostat Innovative air circulation concept - large diameter, quiet low speed; large air volume, low energy consumption, low cost.
All year round can use the fan, not only cool, the winter reversal can thermostat
Innovative air circulation concept - large diameter, quiet low speed; large air volume, low energy consumption, low cost.
项目 | AWF48 | AWF54 | AWF60 | AWF72 | ||||
AWF60-6 | AWF60-8 | AWF60-10 | AWF72-6 | AWF72-8 | AWF72-10 | |||
Number of pages(sheet) | 6 | 8 | 6 | 8 | 10 | 6 | 8 | 10 |
Motor Power(KW) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
Fan diameter(mm) | 4800 | 5400 | 6000 | 7200 | ||||
Maximum speed(RPM) | 55 | 47 | 45 | 45 | 45 | 45 | 45 | 45 |
Overall height(MM) | 1100 | 1100 | 1100 | 1100 | 1100 | 1100 | 1100 | 1100 |
weight(KG) | 98 | 128 | 136 | 142 | 164 | 150 | 163 | 184 |
air flow(CMM) | 7600 | 8760 | 9500 | 10000 | 11000 | 10000 | 11000 | 12000 |
average wind speed(m/s) | 1.8 | 2 | 2.4 | 2.6 | 2.8 | 2.6 | 2.8 | 3 |
Effective coverage area(m2) | 1050 | 1420 | 1500 | 1550 | 1550 | 1600 | 1600 | 1600 |
